- 3" T-Bar and a 6" T-Bar for the ceiling structure.
- The ESC ceiling allows for simple drop-in HEPA filters, Lights and Fan Filter Units.
- Vane Diffuser shown here with Room-side Replaceable Lamps for Pharma Cleanrooms.
- Adjustable Snorkel for exhausting air.
- Sprinkler Head and Piping.
- A series of threaded rods ready to support the ceiling grid.
- Multi-level ceilings in a Cleanroom can be difficult to build, but it is not a problem for ESC's patented system.
- Here are some hanging mid-room electrical outlets.
- Cleanroom ceiling from above.
- Another view from above.
Ceiling Components
Typical construction offers 3″ white powder-coated Aluminum T-Bar extrusions.
Services such as sprinkler Heads, Electrical drops and Gas Ports would be designed into our 6″ T-bar.
